TM45-2 Data Set
| MOUNT TYPE | Spigot | MAIN JET | N100604-Size | 175 |
| TICKOVER POSITION | Left | PILOT JET | VM28/486-Size | 25 |
| COLD START POSITION | Right | NEEDLE JET | 784-430000-Size (723) | Y-6 |
| COLD START TYPE | Cable | JET NEEDLE | 8CFY2-97 | Clip groove #3 |
| AIR SCREW POSITION | Left | STARTER JET | Fixed | — |
| FLANGE PITCH (MM) | — | PILOT AIR JET | — | — |
| CLAMP DIA (MM) | — | PILOT AIR SCREW | VM20/584-Size | 2 Turns out |
| FRONT SPIGOT DIAMETER (MM) | 49 | MAIN AIR JET | BS30/97-Size | 0 |
| REAR SPIGOT DIAMETER (MM) | 65 | POWER JET | — | — |
| LENGTH (MM) | 90 | THROTTLE VALVE | — | — |
| HEIGHT OVER BORE CENTRELINE (MM) | 108 | FLOAT VALVE | 786-27001-Size | 4.2 |
| HEIGHT UNDER BORE CENTRELINE (MM) | 82 | PUMP NOZZLE | TM42/11-Size | 0.70 |
| FUEL INLET POSITION | Left | — | — | — |
| FLOAT HEIGHT (MM) | 18 | — | — | — |
| FUEL SPIGOT (MM) | 8 |
